Fire and smoke engineering for fire-brigade approval
CFD of fire and smoke in buildings, sheds, pavilions, industrial and mining plants, oil and gas platforms and hangars. Visibility, temperature, gases and smoke extraction, with a report for the fire brigade.
Results accepted and approved by the technical staff of the São Paulo fire brigade, including a work that had been embargoed.
Fire and smoke track record
- Approved by the fire brigadeExhibition pavilion in São Paulo: the work was embargoed, and the project was approved after the CFD study.
- Alternative solutionsStudies that propose alternatives to the prescriptive technical instructions, with the safety demonstrated.
- Visibility on four facesVisibility evaluated on the four faces of the pavilion up to 3,600 s after the start of the fire.
- Escape routesVisibility, temperature and gases along the escape routes.
- Client testimonial“…results accepted and approved, including, by the technical staff of the São Paulo fire brigade.” Carlos Cotta Rodrigues, CEO, Carlos Cotta Engenharia.
Complete studies, from the fire scenario to the report for the fire brigade
We prefer whole projects to isolated simulations: ATS issues the study and the documents, and your team reviews and submits.
Smoke control
Extraction, supply and pressure differential, with the position and flow of the smoke-evacuation fans.
Tenability of the escape routes
Visibility, temperature and gases along the escape routes, over time.
Alternative solution
When the prescriptive instruction does not fit the building, we propose an alternative and show it is safe.
Need only a part? We define the scope with you.
What you receive
Fire and smoke spread
Spread based on the heat release rate (HRR) of the fire scenario.
Extraction and pressure differential
Control of smoke with extraction and pressure differential between spaces.
Visibility, temperature and gases
Along the escape routes, over time.
Smoke evacuation
Position and flow of the fans.
Alternative solutions
Alternatives to the prescriptive technical instructions.
Report for the fire brigade
Criteria of visibility and temperature, and the documentation to submit.
How ATS studies fire and smoke
The scenario
Place of the fire, materials, HRR curve and ventilation conditions. The fire is defined by its heat release rate, and the smoke and heat follow from it.
The simulation
Smoke, heat and visibility in time, with CFD, in the geometry of the building and with its extraction and supply systems.
Where it applies
Buildings, sheds, pavilions, industrial and mining plants, oil and gas platforms and hangars.
Tools, and where each one fits
Tools serve the engineering work. We say what each one does in the project.
| Tool | Role in the project | Status |
|---|---|---|
| FDS (Fire Dynamics Simulator), NIST | Fire and smoke simulation: a large-eddy simulation (LES) CFD code for low-speed, thermally driven flow, with emphasis on smoke and heat transport. Free software from NIST (USA), in the public domain. | Free |
| Smokeview, NIST | Visualization of FDS results: smoke, temperature and visibility in 3D and as animations. Free software from NIST (USA), in the public domain. | Free |
| PyroSim | Graphical user interface for FDS, by Thunderhead Engineering: 3D modeling, CAD import (IFC, DWG, FBX), meshes and post-processing of results. | Per project |
| CFD++ | Fluid flow, heat transfer, combustion and particles in 3D. ATS is the exclusive CFD++ representative in Brazil. | Licensed |
| Tecplot 360 EX | Post-processing and automation macros. | Licensed |
